Elevate: Low Slope Roofing Systems

This synthetic elastomeric membrane has been proving itself for over 40 years. Offered in both unreinforced and reinforced as a black membrane in traditional applications or unreinforced as a white membrane when a highly reflective surface is required, EPDM can be used in ballasted, fully adhered, mechanically attached, and protected membrane systems. Its weatherability and low-temperature flexibility make it the ideal choice for the most extreme climates. Platinum EPDM Systems can be warranted up to 30 years.

Today's environmentally friendly choice when reflectivity is required for cooling savings as well as reducing the urban heat-island effect. Strong heat welded seams allow for quick installation in mechanically attached or fully adhered systems. Platinum 30-year warranties are available.

An asphalt-based system that is produced in the factory using today's highly engineered polymer technology to enhance asphalt's natural waterproofing capability and either polyester or fiberglass reinforcement to improve its strength. Red Shield warranties are available for up to 25 years.

The traditional roofing system proven by time. Elevate offers both Type IV and Type VI reinforcing felts as well as hybrid systems incorporating modified bitumen cap sheets. Red Shield warranties are available for up to 20 years.

Elevate's ISOGARD GL is a closed-cell fiberglass-faced polyisocyanurate insulation offered in both flat and tapered panels. ISOGARD GL is manufactured in plants located across the United States and all meeting the rigorous ISO 9002 standard.

• ISOGARD GL can be used in conjunction with any of Elevate's membrane or metal roofing systems.
• ISOGARD GL passes the most stringent fire and wind uplift tests conducted by Factory Mutual Global, Underwriters Laboratories, and Miami-Dade County.
• ISOGARD GL has the highest R-Value per inch of any commercial roof insulation.
• Lightweight and easy to cut makes ISOGARD GL a contractor favorite.
• Its recycled content and energy savings ability help the building owner acquire LEED certification.
• Tapered ISOGARD GL is used to achieve positive drainage in both retrofit and new construction applications.
• When used with Elevate roofing systems ISOGARD GL is included in the total systems warranty.

Tapered ISOGARD GL provides an effective and economical solution where substrate slope will not permit efficient drainage.

Strategic Building Products provides a variety of technical support services for the installation of tapered insulation backed by the Elevate Tapered Engineering Design Department.

Strategic Building Products uses the latest technology to offer architects, consultants, general contractors, distributors and roofing contractors a complete, accurate and timely engineered tapered system. The Elevate Tapered Engineering Design Department is equipped with software that will handle or convert most digitally transmitted drawing formats as well as hard copy prints.

Additionally, Strategic Building Products offers architects and consultants a tapered design assist service. Through this service, Strategic Building Products creates a professional and effective tapered system design for any project prior to bid. Strategic Building Products can provide field estimating services including roof area takeoff and laser level deck elevation conclusions.

Elevate total-system warranties assure complete wind protection from edge to edge. Every building is subject to wind-related roof damage and, all too often, shop-bent edges are installed that do not meet recognized industry standards, resulting in compromised performance. Elevate products are Factory Mutual-approved and have also been independently tested according to ANSI/SPRI ES-I Wind Design Guide. Details, color charts and samples are readily available for submittal and approval.

Elevate's metal products supplies quality coil and flat stock material in a variety of sizes and metals. Elevate facilities are strategically located throughout the country to support our customers' needs with quick and efficient service. Service centers inventory steel and aluminum in a variety of gauges and finishes. Natural metals, such as copper and zinc, are available to support high-end architectural applications. Standard colors and gauges can be found on holcimelevate.com/us.

A variety of soffit panels comprise the Elevate metal products. Most have the capability of being installed in both vertical or horizontal applications and come in a variety of materials and gauges. All soffit panels can be vented to provide air flow at the eaves of your building.

For all of these products we offer design, specification and detail assistance. We also provide complete shop drawings before installation to assure it works and fits right the first time.

We can assist in specifications, design, detail assistance, code compliance and choosing the right contractor.

The SunWave Daylighting System is a premium daylighting product for the commercial roofing industry use for domes, smoke hatches and roof curbs that features a dome formation and unique high-performance frame design that increases visual comfort for people inside the building while conserving energy. The double-glazed SunWave dome formation consists of two prismatic acrylic layers, one clear and the other white. There are over 4,000 tiny prisms per sq. ft. (0.1 sq. m) embedded in each of the dome's two layers. The result is a soft, yet bright natural diffused light, that is distributed throughout the building, without the formation of "hot spots" or glare. The SunWave Daylighting System is available in six standard sizes and can be covered under a 20-year Elevate Red Shield™ Warranty for waterproofing and performance.
